Developing Film at Home Without the Reel Jamming
Loading film on a plastic developing reel and it jams halfway, worse on a humid day? Darkroom regulars switched to a different kind of reel, and it stopped.
As an Amazon Associate I earn from qualifying purchases.
Two ways to read this piece. The quick read tells it in three pictures and a few short paragraphs. The full story is the whole piece, with every source.

The roll that won't go round
Film goes onto the reel unseen, by hand, inside a bag, and on a plastic reel plenty of rolls stop dead. The r/AnalogCommunity member who started the main thread here ran a Paterson tank for years in damp British air. Damp got into the bag and the film, and a spotless reel jammed anyway.
A reply in the thread reports the same jam. A darkroom hand from 1977 never got anywhere with plastic reels either.

A reel that winds from the hub outward
The thread's answer is stainless steel, and the difference is direction. Plastic reels take the film in from the outside and push it the whole way. On steel the film is clipped at the hub and the spiral runs outward, so there's nothing to force.
Not just any steel, mind. The cheap vintage ones tend to arrive bent, which is what puts people off. One reply rates Hewes best, and Amazon carries the Hewes 120 stainless steel reel.

One extra tank, then an evening on the sofa
The catch is the tank. The post that makes a Paterson tank light-tight won't pass through a Hewes reel, so a steel tank goes on the list.
Don't overspend. One reply runs cheap ones fine and says the lid is about all that changes.
That darkroom hand from 1977 sat on the couch with a spare roll and learned to load it without looking. Scratches sent one owner back to plastic, the only such complaint, so get the Hewes.
Want the details?
The full story has the rest, the annoying parts included, and every source.
Developing your own film starts in the dark. Before any chemistry goes near it, the roll has to be wound onto a spiral reel by feel. It happens inside a changing bag or a blacked-out bathroom. For a lot of people, that's the step that goes wrong.
Paterson's plastic reels are the standard ones, and the ones these threads are about. You feed the film in at the outer edge and ratchet it round. On a good day it takes a minute. On a humid one the film grabs, stops, and won't go forward or back.
If your film keeps jamming on the plastic reel, the darkroom regulars in r/AnalogCommunity have a fix, and it isn't a technique. It's a different kind of reel. It comes with one real cost, which we'll get to.
Why does film jam on a plastic reel?
The thread that lays it out is called "I don't know why I didn't try stainless steel reels sooner". The person who started it had used a Paterson tank for years, in the UK, where it's humid most of the year, loading inside a dry bag.
About one in five rolls gave them trouble. The film grabbed and jammed even on clean, dry reels, because everything in the bag went humid, film included.
They're not alone. Someone else in the thread has the same trouble with the standard plastic reels, and a darkroom veteran who started in 1977 never got on with plastic reels at all.
How does a steel reel avoid the jam?
It loads the other way round. On a plastic reel the film goes in at the outer edge and spirals inwards, so every turn pushes more film ahead of it. On a steel reel the film starts at the centre, clipped to the core, and spirals out towards the edge. That's what the thread means by loading "in reverse". Nothing is ever being shoved.
The 35mm reels have a metal clip in the middle that you hook the sprocket holes onto. The 120 reels use a small spring clip instead.
The reels that thread is about are made by Hewes, a small engineering firm in Bedfordshire, England. Its website looks untouched since the nineties. The Hewes 120 reel is on Amazon. The 35mm one isn't, at least not in the US. We'll come to where it is.
Here's what the person who started the thread found after switching:
Enter stainless reels. I've got some Hewes stainless reels in 35mm and 120. I've loaded a dozen rolls with them now and it's zero issue. Quicker and less jammed up rolls when developing. You don't "push" the film on, you load it onto the reels in reverse. No chance of jamming.
u/leekyscallion, in r/AnalogCommunity

Why Hewes, and not any steel reel?
Steel reels have a mixed reputation, and the thread explains why. A lot of the cheap ones are secondhand and slightly bent, so people get frustrated and give up straight away. The same reply's verdict on the Hewes 35mm reels is two words: "top notch".
Another reply ranks Hewes first outright, with Nikkor and Kindermann sharing second place.
Someone who's run a steel tank for nearly forty years, with Hewes and Kindermann reels, says the film all but loads itself.
People who've loaded film for a living back that up. One loaded twenty to thirty rolls every morning in a San Francisco lab in the nineties, and can still feel the steel reels in their hands.
Another wound fifty-plus rolls a day at a commercial lab, on every type of steel reel going, and says "you could never force me to go back to plastic".
The build is the difference. The Hewes 120 reels are wound from thick, chunky wire that lets the film find its way without kinking. The owner who says so finds them even easier to load than the 35mm ones.
Cheap steel reels can also be smaller than they look. Someone bulk-loading long rolls found their cheap reels took about 37 frames and no more, while their Hewes reels had taken 38 without complaint.
They cost more than plastic. Nobody in the thread pretends otherwise, and nobody regrets it.
Once I purchased a couple reels, I was hooked. More expensive but savings in frustration well exceeds the initial purchase price.
u/kleinishere, in r/AnalogCommunity
Will Hewes reels fit a Paterson tank?
No, and this is the cost of switching. A second thread asked exactly that, and four people gave the same answer.
A Paterson tank is light-tight because of its centre post. The lid locks onto a tube that runs up through the reels, and that tube is what keeps the light out. Hewes reels have a smaller core, so the post won't fit through them, and the reels need a steel tank of their own.
Budget for a stainless tank as well, if you don't already own one. Steel tanks, at least, are simple things. By one account they only differ by their lids, and the cheap ones work fine.
One wrinkle: Hewes makes more than one version of its reels. Alongside the standard reel, Freestyle Photo lists versions cut for Jobo 1500 and Jobo 2500 tanks, and one for Jobo 1500 and Paterson tanks. The owner who was hooked bought the Jobo 1500 version, which is a different reel from the one on Amazon.
One reply in the tank thread named a Hewes reel with a one inch core as the exception to the tank rule. Check that with the seller before you count on it.
What steel gets wrong
Scratches, for one owner. The person with the too-small cheap reels went back to plastic in the end, because steel tanks and reels scratch film more easily in their experience. It's the only reason anyone in these threads gave for going back.
120 film is the trickier size on any steel reel. The veteran from 1977 says it's more flexible, so there's more chance of bending it. Bend it and you get a crescent-shaped mark on the negative.
Hewes also matters less with 120, according to the reply that rated the 35mm reels top notch: most steel 120 reels load fine as long as the spirals are parallel. The 35mm reel, with its clip, is where the Hewes name earns the most.
The advice from 1977 still holds. Take a roll of exposed film, sit on the couch with the TV on, and practise loading the steel reel without looking at it. Do it in the light until your hands know the way, then do it in the bag.
What to check before you switch
- Your tank. A stainless tank with a light-tight lid and no centre post, any brand. If all you own is a Paterson, this is the extra purchase.
- Which Hewes reel. The standard reel is the one for a plain steel tank. The Jobo-specific versions are different reels, listed separately, so read the listing before you pay.
- New, not vintage. The bent secondhand reels are where steel got its bad name. Hewes still sells new, direct by email or through camera shops.
- A practice roll. Sacrifice one roll and load it in daylight until you can do it with your eyes shut.

Buy the size you shoot most, and a tank to put it in. For 120 that's the Hewes 120 reel on Amazon. The 35mm reel isn't listed on Amazon in the US at the moment, but B&H, Adorama and Freestyle Photo all carry it. Then spend one evening on the couch with a spare roll before the first real one goes in the bag.
